Qingyun Hongsheng Machinery Parts Co., Ltd. is one of the most reliable manufacturers and suppliers of carbon steel to welding bending head in China. We warmly welcome you to wholesale high quality carbon steel to welding bending head at low price from our factory. If you have any enquiry about quotation, please feel free to email us.
Carbon steel to welding bending head
The butt welding elbow is a steel hot pressed or forged elbow, its connection form is directly welding the elbow and steel pipe.
The main manufacturing standards for butt welding bends are generally GB / T13401-2005, GB / T12459-2005, ASME B16.9, SH3409, HG / T21635, HG / T21631, SY / T0510, GB / T10752-1995.
Classification of welding bending head
(1) The butt welding bend is divided according to its radius of curvature, which can be divided into long radius and short radius. The radius of curvature of the long radius is equal to 1.5 times the outer diameter of the pipe, namely R=1.5D. The radius of curvature of the short radius is equal to the outer diameter of the pipe, namely R=1D. Where D is the diameter of the opposite weld elbow and R is the radius of curvature. If there is no special description, the 1.5D elbow is generally used.
(2) By pressure level, there are about 17 pipes, the same as the United States, including: Sch 5s, Sch10s, Sch 10, Sch 20, Sch 30, Sch40s, STD, Sch 40, Sch 60, Sch80s, XS; Sch 80, Sch100, Sch120, Sch140, Sch160, XXS, the most commonly used are STD and XS.
(3) According to the Angle of the elbow, there are 45 degrees of welding elbow, 90 degrees of welding elbow and 180 degrees of welding elbow and other different angles.
(4) Materials are: carbon steel, alloy steel and stainless steel.
Carbon steel bend advantage
1, do not need the pipe billet as raw material, and can save the cost of pipe equipment and mold, at the same time can get any large diameter and relatively thin wall thickness of carbon steel elbow.
2. The billet is flat plate or curved surface, so the cutting is simple, the accuracy is easy to ensure, and the assembly and welding is more convenient.
3, does not need any special equipment, especially suitable for the site processing of large carbon steel elbow.
4, carbon steel elbow is suitable for petroleum, chemical, hydropower, construction and boiler industry pipeline system.
