Qingyun Hongsheng Machinery Parts Co., Ltd. is one of the most reliable manufacturers and suppliers of wear resistant ceramic lined pipe bend in China. We warmly welcome you to wholesale high quality wear resistant ceramic lined pipe bend at low price from our factory. If you have any enquiry about quotation, please feel free to email us.
Wear Resistant Ceramic Lined Pipe Bend
Wear resistant ceramic lined pipe bends are made by installing special ceramics on the inner wall of the pipe with a high-temperature resistant inorganic adhesive, and forming a firm wear protection layer after being heated and solidified. Wear resistant ceramic lined bends have the performances of high wear resistance, long service life time, and easy installation, and significant economic benefits, widely used for the cement plant, melting, coal power plant, mining and so on.
The pulverized coal transportation and dust removal system pipelines are used to transport high-temperature gas mixed with hard particles. Its operating characteristics are high temperature, high flow rate, high particle hardness, and serious equipment wear, especially the elbow part. The life time is general just one year if there is no protective measures are taken. Most of these equipment are on high-altitude supports, which is inconvenient for maintenance. Once worn out, it will seriously affect the safety.
Kingcera Wear-resistant ceramic lined bend adopts a special design, so that after the last piece of a circle is embedded, a 360° mechanical self-locking force is formed between the ceramic tiles to ensure a tight ceramic bonding. The GWJ series adhesive used for pasting ceramics is a proprietary product jointly developed by our company and Tsinghua University. The adhesive has excellent adhesion to steel and ceramics; it has high strength and toughness; Heat resistance and aging resistance. It can be operated at a temperature of -50°C to 350°C for a long time.
The Wear-resistant ceramic lined bend can be favored by the market and continue to replace some traditional anti-wear materials. The fundamental reason lies in its excellent product quality and its advantages compared with traditional anti-wear materials such as cast Basalt and cast steel.
1,Basalt
In the past, most of the factories use the basalt bends. This material is characterized by fragility, cracks. It usually with 25-35mm thick wear surface backpacks, some are nearly 40 mm. The inner side is ground for a short time. After breaking and cracking, the pulverized coal wears outward along the gap, and its life span will only have one major repair period. Moreover, there are often pores inside, which are easy to leave hidden dangers. Once worn through, the site cannot be repaired.
2,Cast Steel
Cast steel (including alloy steel) is widely used in the field of wear resistance, and its manufacturing process is relatively simple. However, due to the limitations of the performance of the material and the limitation of the process, the surface hardness of cast steel materials (about 60) is much lower than that of ceramics (above 80), and the wear resistance is only equivalent to a few tenths to lower than that of ceramics. (Specific For the data, refer to the wear test report of the Institute of Powder Metallurgy of Central South University and the spray wear test results of the Kyushu Industrial Ceramics Research Institute of Japan). In addition, the cast steel pipeline is thick, very heavy, and has a high carbon content, and the weldability is relatively poor. It requires on-site butt weld heat treatment, which brings considerable difficulties to on-site installation and maintenance.
